門控系統工業電源
詳細描述
| 性能說明: |
| |
| Model |
VP492A |
| Input |
Universal AC voltage |
180-264VAC |
| Frequency |
47~63Hz |
| Efficiency |
72% |
| AC Current(Typ.) |
0.5A |
| Inrush current(Typ.) |
30A |
| One Output |
DC voltage |
+12V1DC |
+12V 2VDC |
+13.8V 3VDC |
| Voltage tolerance |
±5.0% |
±5.0% |
±5.0% |
| Rated current |
1.0A |
2.0A |
0.5A(Battery) |
| Rated Power |
43W |
| Ripple & noise(Max.) |
±1%VP-P |
±1%VP-P |
±1%VP-P |
| Line regulation |
1% |
1% |
1% |
| Load regulation |
2% |
2% |
2% |
| Setup/Rise/Hold time |
3S/10mS/16mS |
| Cooling |
By air |
| Protections |
Over load |
Recovers automatically after fault cleaned. |
| Over voltage |
115%~150% rated output voltage |
| Short circuit |
Recovers automatically after fault cleaned. |
| Overtemperature |
+100℃ |
| Safety & EMC |
Safety standards |
Compliance to UL60950-1 |
| Withstand voltage |
Input to Output:3KVAC,Input/FG:1.5KV,1minute |
| Isolation Resistance |
Input to Output:100MΩ/500VDC |
| EMI conduction&radiation |
Compliance to EN55022 ClassB EN61000-3-2 |
| Environment |
Working Temperature |
-25℃~+40℃ |
| Working Humidity |
20~90%RH |
| Storage Ambient |
-40℃~+70℃,10~95% RH |
| Others |
Dimension |
129X98X38mm(LXWXH) |
| weight |
350g | |
