80w恒流或恒壓可控硅調(diào)光電源


Model and operating parameters:
•Dimming principle:Triac Dimmable / Non-dimmable (Ordinary led driver)
Constant Current:
•Input voltage:100-240VAC/100~120VAC/180~240VAC
•Power:80W
•Output channel: One channel
•Output current:2600mA/2200mA/1800mA/1300mA(can be customized with different needs)
•Output voltage: (34V/40V/50V/66V)±0.5
•Efficiency：80%~86%
•Power factor: >0.9
•Dielectric strength: 3000VAC
•Size:190*65*29mm

Constant Voltage:
•Input voltage:100-240VAC/100~120VAC/180~240VAC
•Power:80W
•Output channel: One channel
•Output current:5500mA/3300mA/1850mA(can be customized with different needs)
•Output voltage: 12V/24V/48V
•Efficiency：80%~86%
•Power factor: >0.9
•Dielectric strength: 3000VAC
•Size:190*65*29mm

Operating characteristic:
•One channel dimmable led driver fit for LED module;
•compliant with SELV standards with output voltage<60DC;
•Efficiency>85%;
•Soft start and low ripple current output;
•Fit for class1 protection lighting fixture
•Have multiple protection for output exception such as open circuit,short circuit,over load etc.
•Fit for both leading edge and trailing edge dimmers
•Dimming range:5%~100%
•Flicker free
•Convenient for lighting design due to its plat case
•Approved by over-temperature protection certification so it can be fit for F class lighting fixture.
•Compliant with international standards such as safety,EMI,anti-interference etc.


Conformance with regulations:
• EN 55015
• EN 61000-3-2CLASSIC
• EN 61000-3-3
• EN 61000-4-2,3,4,5,6,8,11
• EN 61547
