[size=3]Features[/size]

▪ AC Active PFC　Input design

▪ Operating temperature range from　0℃ to　40℃

▪ Build in DC remote ON/OFF , PG/PF TTL signal

▪ Build in long life ball bearing fan

▪ Single Removable Power Supply

▪ Compiles with FCC Class B,CISPR Pub. 22,

　 EN55022 Class B, and CE requirements

▪ UL/cUL 60950, TUV and CB EN 60950 certified

▪ MTBF 100KHRs @ 25℃ per MIL- HDBK-217F

▪ 2 years manufacturer warranty

[size=3]　
Specifications　[/size]

▪ Input Voltage 90-264Vac

▪ Input Current 5.0A max

▪ Input Frequency 50/60 Hz

▪ Efficiency >65% @ full load ,nominal line

▪ Inrush Current 80A max @230Vac 25 ℃ cold start

▪ Leakage Current　0.75mA max. @115Vac input



[IMG]200692819554663339.jpg[/IMG]
