產品詳情
Functional Characteristics 電氣特性
|
測試電流Testing current |
熔斷時間Blow Time | |
|
Min最小 |
Max最大 | |
|
100% |
4h |
/ |
|
200% |
1s |
60s |
|
|
Breaking Capacity 分斷能力 | |
|
50 amperes at 125V AC (200mA-6.3A) | ||
|
50 amperes at 250V AC (200mA-6.3A) | ||
|
Material 材料 | ||
|
Fuse body –CERAMIC TUBE | ||
|
End cap--nickel plated brass | ||
|
Pigtail--tin plated copper on nickel plated brass cap | ||
Approvals認證（○ Pending ● Approvals）
|
額定電流Current Rating |
額定電壓VoltageRating |
認證Approvals | |||||||
|
| |||||||||
|
200mA |
125V/250V |
● | |||||||
|
250mA |
125V/250V |
● | |||||||
|
300mA |
125V/250V |
● | |||||||
|
315mA |
125V/250V |
● | |||||||
|
350mA |
125V/250V |
● | |||||||
|
400mA |
125V/250V |
● | |||||||
|
500mA |
125V/250V |
● | |||||||
|
600mA |
125V/250V |
● | |||||||
|
630mA |
125V/250V |
● | |||||||
|
750mA |
125V/250V |
● | |||||||
|
800mA |
125V/250V |
● | |||||||
|
1A |
125V/250V |
● | |||||||
|
1.25A |
125V/250V |
● | |||||||
|
1.5A |
125V/250V |
● | |||||||
|
1.6A |
125V/250V |
● | |||||||
|
2A |
125V/250V |
● | |||||||
|
2.5A |
125V/250V |
● | |||||||
|
3A |
125V/250V |
● | |||||||
|
3.15A |
125V/250V |
● | |||||||
|
3.5A |
125V/250V |
● | |||||||
|
4A |
125V/250V |
● | |||||||
|
5A |
125V/250V |
● | |||||||
|
6A |
125V/250V |
● | |||||||
|
6.3A |
125V/250V |
● | |||||||
